AMERICAN STANDARD |
|
METRIC |
|
|
||
|
Handle No. |
In. Lbs. |
Ft. Lbs. |
|
M. Kg. |
N.M. |
OAL (“) |
Weight. (lbs) |
|
400 |
20-240 In. Lbs. |
2-20 Ft. Lbs. |
|
0.28-2.77 M.Kg. |
2.71-27.11 N.M. |
8 1/2 |
1 |
|
500 |
100-800 In. Lbs. |
8-65 Ft. Lbs. |
|
1.11-8.99 M.Kg. |
10.84-88.11 N.M. |
12 1/2 |
3 |
|
600 |
180-1200 In. Lbs. |
15-100 Ft. Lbs. |
|
2.07-13.83 M.Kg. |
20.33-135.56 N.M. |
15 |
4 |
|
700 |
400-1800 In. Lbs. |
30-150 Ft. Lbs. |
|
4.15-20.75 M.Kg. |
40.67-203.34 N.M. |
20 |
4 |
|
800 |
540-2400 In. Lbs. |
45-200 Ft. Lbs. |
|
6.22-27.66 M.Kg. |
61.00-271.12 N.M. |
23 |
5 |
|
900 |
900-2400 In. Lbs. |
|
|
10.37-27.66 M.Kg. |
101.67-271.12 N.M. |
28 |
5 |
|
MODEL No. |
Ratchet |
Scale |
|
Scale |
|
One |
Low |
OAL |
Weight |
Adj. Key |
||
|
|
End Size |
Ft. Lbs. |
Inc. |
In. Lbs. |
Inc. |
Turn |
End |
(“) |
(lbs) |
Size |
||
|
SE 00 RA |
1/4" |
1-10 |
1 |
10" lbs. |
10 |
1/2# |
10" |
12.75 |
2 |
1/8 |
||
|
SE 02 RA |
3/8" |
1-10 |
1 |
10" lbs. |
10 |
1/2# |
10" |
12.75 |
2 |
1/8 |
||
|
SE 12 RA |
3/8" |
1-20 |
2 |
20" lbs. |
20 |
2# |
20" |
12.75 |
2 |
1/8 |
||
|
SE 22 RA |
3/8" |
5-50 |
5 |
50" lbs. |
50 |
5# |
50" |
15.88 |
4 |
3/16 |
||
|
SE 33 RA |
1/2" |
10-150 |
10 |
10 ft. lbs. |
100 |
10# |
120" |
23.38 |
5 |
3/16 |
||
|
SE 44 RA |
1/2" |
30-250 |
10 |
30 ft. lbs. |
100 |
10# |
30# |
24.5 |
6 |
3/16 |
||
|
SE 55 RA |
3/4" |
50-350 |
25 |
50 ft. lbs. |
250 |
25# |
50# |
36.25 |
12 |
3/16 |
||
|
SE 65 RA |
3/4" |
100-600 |
50 |
100 ft. lbs. |
500 |
50# |
100# |
36.25* |
18 |
3/4 |
||
|
|
|
|
|
|
|
|
* 54 3/4 w/extension handle |
|||||
